OS
Android 8.1 / 11 / 13 / 14
Windows 10 / 11, Linux
Processor
RK3566 / RK3568 / A527
J6412 / N95 / N97 / N100 / i3 / i5 / i7
Memory
RAM 2 / 3 / 4 / 8 GB
RAM 4 / 8 / 16 GB
GPU & Graphics chipset
ARM G52 2EE
Intel® UHD Graphics
Storage
32 / 64 GB
NVMe M.2: 128 / 256 / 521 GB
LCD
11.6’’ TFT ( 1366*768 ); optional: 11.6” FHD ( 1920*1080 )
Touch screen
PCAP panel
Brightness
300 cd/m2
Printer
Inbuilt 80mm thermal printer with cutter
Paper size: 80*60 or 58*60 ( thermal receipt & thermal sticker )
Support: ESC / POS commands & OPOS driver
Interface: USB + RS232 port
Serial ports
1 serial ports
USB
3 x USB 2.0 + 2 x USB 3.0
LAN
Gigabit Ethernet x 1 ( RJ-45 )
Cash drawer
( RJ-12 6 Pins ) x 1 / support ( 9 - 24V ) cash drawer
Audio
1 x Jack
Sim slot
4G sim
/
TF slot
128G max
VGA
VGA display port x 1
Power supply
1x DC, 12V, 7A
Dimensions (L x W x H)
29 x 30 x 10 cm
Weight
3 - 3.8 kg depending on version and options
Options
DALLAS reader
1 slot (USB or RS232 port)
WiFi
802.11 b/g/n, 2.4/5G
Customer display
VFD (2 x 20) or 4.3’’ ( 800 x 480 )
NFC
NFC reader ( USB or COM port )
Barcode reader
1D/2D/QR code reader
